ADVANTAGES:
Waterproof, shock-resistant, corrosion-resistant and durable
Reliable locking performance with metal shrapnel in the lock part
Stable reading as the chip is located outside the tied area, unaffected by the material of the tied object
Effective in preventing cargo tampering and loss
MAIN FEATURES:
Made of PP plastic
Metal shrapnel in the lock part for excellent non-removable locking effect
Chip positioned externally to avoid interference from tied materials
Customizable chip models available
APPLICATIONS:
Container and cargo container management
Prevention of cargo tampering and loss
Cargo information inquiry, inventory and verification
Logistics and transportation tracking
Other similar operation scenarios requiring secure fastening and tracking
CHARACTERISTICS：
Item | Details |
Compliance | ISO/IEC 18000-6C |
Frequency | 915MHz |
Chip | Alien H3 (other models can be customized) |
Memory | Refer to Alien H3 chip specifications (or customized chip) |
Read/write | Refer to chip specifications |
Data Storage | Refer to chip specifications |
Lifetime | Durable (suitable for long-term logistics use) |
Material | PP plastic |
Dimension(mm) | - Label size: 105×30×2.7 |
Storage Temperature | Refer to industry standards for similar container tags |
Operating Temperature | -10～65℃ |
Mechanical Resistance | Shock-resistant, suitable for transportation environments |
Delivery format | Single |
Installation Method | Insert the tie strip into the lock (non-removable after insertion) |
Weight | Refer to actual product specifications |
Package | Refer to industry standards for similar tags |
Color | Refer to actual product specifications |
Power Supply | Passive (depending on chip type) |
Chemicals | Corrosion-resistant (suitable for logistics environments) |
RoHS | Refer to material and chip specifications |
Read distance | 10-12m (fixed reader); 2-3m (handheld reader) (varies by equipment and power) |
Polarization | Refer to chip specifications |
ESD Voltage Immunity | Refer to chip specifications |
The metal shrapnel in the lock ensures the tie strip cannot be withdrawn after insertion, providing secure locking.
Different reading performance with different reading facilities and power levels.
The external chip position ensures stable reading regardless of the container or cargo material.
