ADVANTAGES:
Reliable performance for applications in clothing and logistics fields
Both material and design have been tested for reliability
100% function tested
Long reading distance for efficient tracking and management
MAIN FEATURES:
Fixed size: 63*31mm
Reading distance: ≥5m
Integrated chip: Impinj Monza R6-P
High temperature resistant material
Can be lasered with barcode
Resistant to waterproof
APPLICATIONS:
Clothing management
Logistics tracking
Apparel inventory control
Supply chain management
Shipping and distribution tracking
CHARACTERISTICS：
Item | Details |
Compliance | EPC Class1 Gen2; ISO18000-6C |
Frequency | 902-928MHz, 865~868MHz (Can customize frequency) |
Chip | Impinj Monza R6-P |
Memory | EPC 96bits, User 32 bits |
Read/write | Yes (EPC) |
Data Storage | 20 years |
Lifetime | 200 wash cycles or 2 years from shipping date (whichever comes first) |
Material | Packaging material (to be specified); Textile (reference for base material) |
Dimension(mm) | 63*31 |
Storage Temperature | -40℃~ +85 ℃ |
Operating Temperature | 1) Washing: 90℃(194οF), 15 minutes, 200 cycles |
Mechanical Resistance | Up to 60 bars |
Delivery format | Single |
Installation Method | 1) Sewing or put into pouch/hem (suitable for clothing) |
Weight | 0.6 ~ 0.8g (reference for similar tags) |
Package | Antistatic bag and carton |
Color | White (reference for similar tags) |
Power Supply | Passive |
Chemicals | Normal common chemicals in the washing processes |
RoHS | Compatible |
Read distance | ≥5m |
Polarization | Liner |
ESD Voltage Immunity | Refer to Impinj Monza R6-P chip specifications |
During sewing installation, the stitching should not damage the metal wire and chip module.
Different reading performance with different reading facilities.
Hot installation, when the temperature is lower than 210℃ or the pressure is less than 0.6 Mpa, there will be a hidden trouble of bad hot stamping effect.
