ADVANTAGES:
More than 200 wash cycles.
Both material and design have been tested for reliability.
100% function tested.
MAIN FEATURES:
Can customize size for customers.
High temperature resistant material.
Can be lasered with barcode.
Resistant to waterproof.
APPLICATIONS:
Industrial washing.
Management of uniforms.
Medical apparel management.
Military clothing management.
Personnel patrol management.
CHARACTERISTICS：
Compliance | EPC Class1 Gen2, ISO18000-6C |
Frequency | 845~ 950MHz |
Chip | Impinj R6P |
Memory | EPC 96bits,User 32bits |
Read/write | Yes |
Data Storage | 20 years |
Lifetime | 200 wash cycles or 2 years from shipping date (whichever comes first) |
Material | Textile |
Dimension | LxWxH: 58 ( 2.283 inch) x 15 (0.590 inch) x 1.5 (0.059 inch) mm |
Storage Temperature | -40℃~ +85 ℃ |
Operating Temperature | 1) Washing: 90℃(194οF), 15 minutes, 200 cysle 2) Pre-drying in Tumbler: 180℃(320οF), 30minutes 3) Ironer: 180℃(356οF), 10 seconds, 200 cycles 4) Sterilization Process: 135℃(275οF), 20 minutes |
Mechanical Resistance | Up to 60 bars |
Delivery format | Single |
Installation Method | Thread installation |
Weight | ~ 0.6g |
Package | Antistatic bag and carton |
Color | White |
Power Supply | Passive |
Chemicals | Normal common chemicals in the washing processes |
RoHS | Compatible |
Read distance | Up to 5.5 meters (ERP=2W) Up to 2 meters ( With ATID AT880 handheld reader) |
Polarization | Liner |
* During sewing installation, the stitching should not damage the metal wire and chip module.
* Different reading performance with different reading facilities.
* Hot installation, when the temperature is lower than 210℃ or the pressure is less than 0.6 Mpa, there will be a hidden trouble of bad hot stamping effect.
