ADVANTAGES:
More than 200 wash cycles.
Both material and design have been tested for reliability.
100% function tested.
MAIN FEATURES:
Can customize size for customers.
High temperature resistant material.
Can be lasered with barcode.
Resistant to waterproof.
APPLICATIONS:
Industrial washing.
Management of uniforms.
Medical apparel management.
Military clothing management.
Personnel patrol management.
CHARACTERISTICS：
Compliance | EPC Class1 Gen2; ISO18000-6C |
Frequency | 902-928MHz , 865~868MHz (Can customize frequency) |
Chip | NXP Ucode7M / Ucode8 |
Memory | EPC 96bits |
Read/write | Yes (EPC) |
Data Storage | 20 years |
Lifetime | 200 wash cycles or 2 years from shipping date (whichever comes first) |
Material | Textile |
Dimension | 70( L) x 15( W) x 1.5( H) (Cancustomizethesizes) |
Storage Temperature | -40℃~ +85 ℃ |
Operating Temperature | Washing: 90℃(194οF), 15 minutes, 200 cysle Pre-drying in Tumbler: 180℃(320οF), 30minutes Ironer: 180℃(356οF), 10 seconds, 200 cycles Sterilization Process: 135℃(275οF), 20 minutes |
Mechanical Resistance | Up to 60 bars |
Delivery format | Single |
Installation Method | 7015-7M :Thread installation |
Weight | ~ 0.7g |
Package | Antistatic bag and carton |
Color | White |
Power Supply | Passive |
Chemicals | Normal common chemicals in the washing processes |
RoHS | Compatible |
Read distance | Up to 5.5 meters (ERP=2W) Upto 2 meters( With ATIDAT880handheldreader) |
Polarization | Liner |
During sewing installation, the stitching should not damage the metal wire and chip module.
Different reading performance with different reading facilities.
Hot installation, when the temperature is lower than 210℃ or the pressure is less than 0.6 Mpa, there will be a hidden trouble of bad hot stamping effect.
